A-NVXD4 — Brick - Horizontal Metal Transition - Section

Architectural · A-NVXD4

Brick - Horizontal Metal Transition - Section

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.21
Discipline: Architectural

Materials

Aluminum Brick Composite Metal (misc.)Steel

Elements

Anchors / Embeds Facades / Cladding Waterproofing / Flashing

Text on the drawing

MATCH FLASHING AT EAST TERRACE 6" HEAVY GAUGE SILL FLASHING SAM SILL FLASHING STEEL SUB SILL FURRING. PROVIDE CONTINUOUS SURFACE FOR SAM SILL FLASHING C-METAL EW7 EW7 EW2 EW2 HORIZONTAL METAL CLADDING WRB. LAP OVER SILL FLASHING 3/4" VERTICAL FURRING
