The base of a light-gauge steel stud partition wall connects to a concrete floor slab. The wall track sits two inches from the designated grid line. A continuous transition or flashing element separates the bottom track from the slab surface. Concrete slab 1-02 integrates with adjacent materials specified by codes 07 1113.A, 07 2100.F, and 03 3000.A.
