Accessible space layout showing wheelchair user dimensions and reach ranges per accessibility standards. The side reach ranges from a minimum height of fifteen inches to a maximum of forty-eight inches above the finished floor. An unobstructed side reach configuration allows a maximum ten-inch depth.
UNOBSTRUCTED SIDE REACH (CBC2016 FIGURES 11B-308.3.1) 15 MIN 48" MAX. 10" MAX UNOBSTRUCTED SIDE REACH (CBC2016 FIGURES 11B-308.3.1) 4 WHEELCHAIR TURNING SPACE
