A W14x crane runway beam bears on a base plate measuring 3/4 inch by 10 inches by 1 foot 4 inches, anchored to a concrete pilaster and concrete wall per plans. The base assembly sits on approximately 2 inches of non-shrink grout. Two 3/4-inch diameter headed anchor bolts with leveling nuts and oversized holes secure the plate with a 16-inch minimum embedment.
W14x CRANE RUNWAY BEAM (SEE PLAN) CONCRETE PILASTER (SEE PLAN) BASE PL 3/4x10x1'-4" 2"± NON-SHRINK GROUT (2) 3/4"Ø HEADED ANCHOR BOLTS W/ LEVELING NUT W/ 16" MIN EMBEDMENT W/ OVERSIZED HOLES CONC WALL PER PLANS 5 1/2" 10" 6" 5 - S101/TYP, S140/TYP, S144/TYP, AND S180/TYP.
