An aluminum mullion section frames the glazing at the head condition, positioned with a four-inch dimension from the panel face. The storefront abuts a concrete tilt-up panel detailed on structural drawings. A three-eighths-inch joint between the storefront frame and the concrete panel receives sealant over a backer rod.
