Architectural · A-NPAB7

Base Cabinet Anchorage and ADA Lavatory Clearance Details

Materials

anchor

Elements

Doors Millwork / Casework Anchors / Embeds

Connections

Base Plate / Anchorage Bolted Connection Embed Plate

About this detail

Base cabinets are anchored using continuous wood framing members secured with three-eighths-inch expansion bolts with two-inch minimum embedment at sixteen inches on center maximum, alongside number ten by three-inch wood screws at twenty-four inches on center. The assembly incorporates continuous two-by framing and cabinet doors, with specific framing positioned at ends and twenty-four inches on center maximum unless otherwise noted, referencing ICC report ESR-4266. A parallel diagram establishes ADA accessibility clearances for a lavatory, designating a two-foot-ten-inch apron height above finished floor, two-foot-five-and-a-half-inch clear height, and two-foot-three-inch clear height alongside specified toe and knee clearance zones.
