Architectural · A-NNAPR

Window Wall Opening Jamb Detail at Stucco Wall

Materials

Steel Cold-formed Steel Timber / Wood Glass / Glazing Metal (misc.)Gypsum / Drywall EIFS / Plaster / Stucco

Elements

Columns Walls Doors Windows Curtain Walls Insulation Roof / Floor Openings

Connections

HSS Connection

About this detail

Jamb condition for a window wall opening intersecting an HSS column and cold-formed metal stud framing. The assembly features an EFCO window or door unit secured with an EFCO 'F' clip, sealed with continuous sealant and backer rod over shims. The exterior wall build-up consists of a three-coat stucco finish over 1/2-inch sheathing, a vapor retarder extended to the back of the opening, and a metal stucco J-mold. The interior side is finished with 5/8-inch gypsum wallboard over metal stud framing with internal batt insulation and wood blocking adjacent to the structural column.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
