A-NMR6V — Plan Detail Room 130

Architectural · A-NMR6V

Plan Detail Room 130

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Gypsum / Drywall Timber / Wood

Elements

Columns Floors / Slabs Insulation Partitions Walls

Text on the drawing

4 K ACOUSTIC WALL ASSEMBLY, RE: FLOOR PLANS CL 1'-1 1/2" 11 5/8" 4" 2" A2 A-534 ACOUSTIC WALL ASSEMBLY, RE: FLOOR PLANS 1'-2" 6 3/4" ACOUSTIC WALL ASSEMBLY, RE: FLOOR PLANS ISOLATION STRIP BETWEEN STUD & COLUMN
