A-NKT59 — Typical Stair at Floor

Architectural · A-NKT59

Typical Stair at Floor

Scale: SCALE: 1 1/2" = 1'-0"
Units: imperial
Sheet: A5
Discipline: Architectural

Materials

Concrete Glass / Glazing Metal (misc.)Steel

Elements

Beams Connections / Plates Decks Floors / Slabs Stairs Walls

Text on the drawing

BEAM - RE: STRUCTURAL 11" 1" SEE STAIR SECTION CONCRETE FILLED STEEL PAN TREADS STEEL STRINGER RE: STRUCTURAL CONCRETE ON METAL DECK BENT PLATE SOUND WALL BETWEEN MECH. UPPER SLAB & MECH. LOWER SLAB
