A methane pipe penetration passes through a structural roof deck carrying a barrier board, adhered insulation, and a hot-air welded PVC roof membrane. A steel pipe support rests on a steel plate below the roof assembly. A PVC base flashing is mechanically fastened to the deck using one-quarter-inch Simpson SDS stainless steel screws at sixteen inches on center with Sarnadiscs where crickets do not occur. A PVC flashing boot extends up the methane pipe and is secured with a stainless steel hose clamp and PVC sealant. Overlapping base flashings are notched and overlapped between penetrations.
METHANE PIPE PENETRATION PVC SEALANT (SEE NOTE) STAINLESS STEEL HOSE CLAMP PVC FLASHING BOOT PVC BASE FLASHING, HOT-AIR WELDED ROOF MEMBRANE, ADHERED INSULATION ADHERED AS OCCURS PER ROOFING SYSTEM TYPE ASSEMBLY 1/4" BARRIER BOARD STRUCTURAL ROOF DECK 1/4" SIMPSON SDS SS SCREW (ESR 2236) @ 16"OC W/ SARNADISC (ESR 1157) WHERE CRICKETS DO NOT OCCUR 5 1/2" TYP. OVERLAPPING BASE FLASHINGS TO BE OVERALPPED IN BETWEEN AND NOTCHED FOR OTHER PENETRATION STEEL PIPE SUPPORT STEEL PLATE FOR STEEL PIPE SUPPORT
