A-NKNH9 — Enlarged East Wall Gutter - Conductor Head

Architectural · A-NKNH9

Enlarged East Wall Gutter - Conductor Head

Scale: 3" = 1'-0"
Units: imperial
Sheet: A-412
Discipline: Architectural

Materials

Elements

Connections / Plates Drainage Roofs Walls Waterproofing / Flashing

Connections

Welded Connection

Text on the drawing

VARIES 11" AT LOW POINT 3' - 1 1/2" 1' - 0" 6" GSM CONDUCTOR HEAD. 6 SIDED BOX, FULLY WELDED FOR A WATER TIGHT CONDITION. PLUMBING ENGINEER TO VERIFY SIZE TO HANDLE EXPECTED RUN OFF. GUTTER. DISCHARGE INTO CONDUCTOR HEAD GUTTER DISCHARGE BY PLUMBING ENGINEER. SPD.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
