A decorative wood panel is secured by hardwood stops to a wood frame member resting atop a granite top. The granite top is supported by a wall constructed as scheduled. Centerline alignment is maintained through the vertical assembly.
DECORTAIVE WOOD PANEL HARDWOOD STOPS WOOD FRAME MEMBER GRANITE TOP WALL AS SCHEDULED CL CL
