About this detail

This stone detail shows a facade transition between Bethal White granite and Temple White granite panels. A three-eighths inch horizontal joint separates the granite stones, filled with backer rod and sealant. Dimensional callouts indicate precise reveal and thickness increments including one-quarter inch, one-half inch, one inch, one and five-eighths inches, three inches, three and one-quarter inches, and four inches.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
