The concrete tilt-up wall panels meet at an exterior corner with a three-quarter-inch panel joint. A backer rod is installed at each face of the joint with continuous sealant extending from the footing to the top of the panel and across the joint. A three-quarter-inch chamfer is provided at the exterior corner typical.
CONC. TILT- UP WALL PANEL BACKER ROD AT EACH FACE WITH CONTINUOUS SEALANT FROM FOOTING TO TOP OF PANEL AND ACROSS 3/4" PANEL JOINT TYPICAL 3/4" 3/4" CHAMFER TYPICAL
