A-NE3KX — Precast Base Of Wall

Architectural · A-NE3KX

Precast Base Of Wall

Scale: SCALE: 3" = 1'-0"
Units: imperial
Sheet: A501
Discipline: Architectural

Materials

Elements

Expansion / Control Joints Floors / Slabs Insulation Site / Paving Walls Waterproofing / Flashing

Connections

Expansion / Slip Connection

Text on the drawing

VAPOR RETARDER COMPACTED FILL INSULATED PRECAST CONCRETE WALL PANEL, PAINTED. CONT. SEALANT COMPRESSIBLE FILLER CONCRETE SLAB ON GRADE GRADE (REF CIVIL) 8" TYPICAL 3" TYPICAL 2" 3"
