A buckling-restrained brace connects to a gusset plate welded near the base of a steel column. The column is supported by a base plate sized per plan, with ground level established at elevation fifty-four feet one inch. A gusset plate is installed per the buckling-restrained brace manufacturer's specifications and connects to the brace member. Stiffeners are provided on each side of the column web only if required by the manufacturer.
GROUND 54' - 1" 7 MEMBER PER PLAN BRB PER PLAN GUSSET PER BRB MFR BASE PLATE PER 3.S-503 STIFFENER PER 2/3.S-510 EA SIDE OF COLUMN WEB, ONLY IF REQ BY BRB MFR
