An exterior door with a sweep seal meets an aluminum threshold set over a floor panel and existing concrete floor. The adjacent floor assembly consists of three and three-quarters inches of tile, grout, and concrete topping over one and one-quarter inches of leveling sand, with both layers noted as being installed by others. A two-inch mandatory backfill is specified adjacent to the existing floor construction.
SECTION F - F 8" 4" THRESHOLD SWEEP DOOR EXISTING FLOOR FLOOR PANEL 2" MANDATORY BACKFILL REQUIRED (BY OTHERS) TILE/GROUT/CONCRETE 3 3/4" TOTAL THICKNESS (BY OTHERS) 1/4" LEVELING SAND (BY OTHERS)
