This stair railing detail shows an assembly with a 3-inch by 1-inch flat bar top rail and offset riser configuration. The construction includes end views, a top view, and an elevation showing dimensional clearances of 1 1/2 inches and 3 5/8 inches. Field splices require welding and grinding smooth, with field trimming performed as necessary.
END VIEW 1 1/2" 1 1/2" ELEVATION TOP VIEW FIELD SPLICE, WELD & GRIND SMOOTH (FIELD TRIMMING MAY BE REQUIRED) 1 1/2" 3 5/8" 3"X 1" FLAT BAR
