A cold-formed steel stud back-up assembly utilizes 6-inch by 54-mil studs spaced at 16 inches on center. A minimum stud size of TD 600T200-54 is specified, with back-up bridging plates installed between studs or as noted. The connection is secured via welded web-to-flange attachments, shown with 1/8-inch welds at 1-inch spacing.
1/8" 1" 6"X54 MILS @ 16" O.C. (MIN. STUD SIZE) BACK-UP TD 600T200-54 (UNP) BETWEEN STUDS OR AS NOTED 1/8" 1" TD 6x54 MIL BACK-UP WITH WELDING 1/8" 1" BACKUP WEB TO STUD FLANGE BACK UP WEB TO STUD FLANGE (ALTERNATE METHOD)
