Precast concrete wall panel details featuring reinforced sections with continuous horizontal and vertical reinforcing bars, ties, and diagonal corner bars. The assembly includes number five continuous bars, number four bars spaced at eight and one-half inches on center, and number three ties at eight inches on center. Top of panel elevations and lap splice lengths are detailed with standard hooks and drip edges at the glazing interface per architectural requirements.
SEE ELEV t REINF SEE PANEL ELEV #4 @ 8 1/2"OC (2) #5 CONT FULL WIDTH OF PANEL #5 CONT GLAZING PER ARCH SEE ELEV SEE ELEV SEE ELEV 3'-0" LAP TYP T.O.P. VERT REINF SEE PANEL ELEVS (3) #5 EF W/ HOOKS W/ #3 TIES @ 8"OC SEE ELEV SEE ELEV T.O.P. (3) #5 EF FULL WIDTH OF PANEL W/ #3 TIES @ 8"OC VERT REINF SEE PANEL ELEVS (2)#4 x 4'-8" DIAGONAL, TYP R WALL PANEL DETAIL N.T.S. ELEVATION ELEVATION 8" N WALL PANEL SECTION N.T.S. DRIP
