This horizontal plan detail shows a structural steel column wrapped with a multi-sided architectural enclosure. The outer perimeter features custom light interference coating finish panels designated as 08 4400 E-MTL-05. Attachment brackets and mechanical fasteners secure the enclosure framing back to the surrounding framework.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
Start membership
