An interior structural steel post is welded to a deck plate supported by a beam sized per structural plans. A toeboard extends upward from the base assembly, secured with three-sixteenth-inch welds. Gaps around the connection are filled with sealant.
3/16 2-6 BEAM PER STRUCTURAL POST DECK PLATE C L 2-6 2" 3/16 TOEBOARD FILL GAPS W/ SEALANT
