A three-eighths-inch thick gusset plate connects diagonal structural members to a horizontal beam and vertical column per plan. Five-sixteenths-inch fillet welds secure the gusset plate and framing members. The connection is located at the roof elevation of one hundred fifty-two feet five inches.
RAE ROOF 152' - 5" 11 5 3/4" 1' - 11 1/2" 1/2" 7" MIN GUSSET PL 3/8" MEMBER PER PLAN 5/16 5/16 SFRS MEMBER PER PLAN 5/16 N&F MEMBER PER PLAN 6 3.S-331
