A-N6RPM — Waterproofing at Elevator Pit

Architectural · A-N6RPM

Waterproofing at Elevator Pit

Materials

Elements

Walls Waterproofing / Flashing

About this detail

An elevator pit concrete wall bears against eighty-five percent compacted soil with an intervening pre-applied sheet membrane waterproofing layer. A one-quarter-inch protection board shields the membrane on the soil side. The sheet membrane features a typical four-inch lap joint secured with a six-inch wide tape.

ELEVATOR PIT WALL, S.S.D. 4" LAP TYP. PRE-APPLIED SHEET MEMBRANE WATERPROOFING PRE-APPLIED SHEET MEMBRANE WATERPROOFING TAPE, 6" WIDE 85% COMPACTED SOIL, S.C.D. 1 4 " PROTECTION BOARD

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
