The equipment platform interfaces with a structural column in a data hall environment. The platform edge maintains a twelve-inch offset from the column face, with structural framing integrated into the floor assembly. The column sits at the corner of the platform, and the surrounding floor slab extends to accommodate the equipment layout. Spatial clearance dimensions of twelve inches are provided for the platform perimeter.
Text on the drawing
12" 12" 12" EQUIP PLATFORM DATA HALL
