A two-by-twelve-inch aluminum rectangle tube louver is oriented forty-five degrees from vertical and secured to a steel attachment channel with anchor screws. The attachment channel itself is fastened to a hollow structural section column with anchor screws. Painted aluminum decorative caps finish the assembly on the exterior ends. The louver members project outward to form a sunshade or architectural screen.
054000 - 2"X12" ALUMINIUM RECTANGLE TUBE LOUVER ORIENTED 45 DEGREES FROM VERTICAL 055000 - PAINTED ALUMINIUM DECORATIVE CAP 055000 - STEEL ATTACHMENT CHANEL 055000 - SCREWS ACNHOR ATTACHMENT CHANEL TO HSS 055000 - SCREWS ACNHOR LOUVER TO ATTACHMENT CHANEL 055000 - PAINTED ALUMINIUM DECORATIVE CAP
