A Schluter Reno-U satin anodized aluminum transition strip bridges the height difference between a thin-set tile assembly and an exposed concrete floor slab at a doorway. The thin-set tile assembly consists of tile set over grout on a concrete slab substrate. The aluminum transition strip is secured adjacent to the door threshold, maintaining a maximum one-quarter inch tolerance for level changes.
TRANSITION STRIP: SCHLUTER RENO-U SATIN ANODIZED ALUMINUM THIN SET TILE ASSEMBLY TILE AS SCHD. GROUT DOOR AS SCHD. CONC. SLAB, S.S.D. 1/4" MAX 1/4" MAX. EXPOSED CONC. FLOOR TOS 2 1
