Architectural · A-N4PDW

Head Condition Perpendicular to Metal Deck with Ceiling Transition

Materials

Steel Metal (misc.)Gypsum / Drywall

Elements

Ceilings Decks Bracing

Connections

Bracing Connection Deck Attachment

About this detail

The wall assembly features cold-formed steel studs spaced at sixteen inches on center with a top track attached to a twelve gauge continuous sheet steel plate below the metal deck. A diagonal lateral brace spaced at forty-eight inches on center frames into the top track, secured with sheet metal screws. A three-inch by three-inch by sixteen gauge continuous sheet metal angle connects to the studs with flat head sheet metal screws, supporting a suspended gypsum board ceiling with corner trim. The metal deck receives four number twelve sheet metal screws at each flute, with a maximum twelve-inch spacing. Number twelve sheet metal screws at eight inches on center maximum secure the framing components.
