A precast concrete wheel stop sits atop a concrete paving or curb substrate, secured in place with vertical anchor dowels. The wheel stop stands six inches high with an eight-inch top width and features angled side profiles. Dimensional callouts indicate placement parameters relative to the parking stall layout, including a two-foot override clearance. Associated notes specify using a six-foot long wheel stop centered at double stall conditions, and a four-foot long wheel stop set one foot from the centerline at single stall conditions.
