An acoustical joint details the intersection between a ceiling assembly and a wall or roof structure, incorporating a one-quarter-inch gap to isolate sound transmission. The ceiling consists of gypsum board layers supported by framing members and an angle profile at the perimeter. A sealant or filler is applied within the joint space to maintain acoustical separation between adjacent spaces.
