An aluminum curtain wall system mullion sits below metal stud framing with shims inserted as required for alignment. A pre-finished aluminum Z flashing matching the aluminum mullion is integrated at the junction with a backer rod and sealant joint. The metal soffit framing supports a direct-applied finish system that meets the head of the storefront assembly, adjacent to the outline of a future finish.
METAL STUD FRAMING INSULATED GLASS ALUMINUM CURTAIN WALL SYSTEM MULLION SHIM, AS REQUIRED OUTLINE OF FUTURE FINISH BACKER ROD AND SEALANT PRE-FINISHED ALUMINUM Z FLASHING TO MATCH ALUMINUM MULLION METAL SOFFIT FRAMING DIRECT-APPLIED FINISH SYSTEM
