A-MVZK8 — Horizontal Metal Panel - Vertical Joint - Plan

Architectural · A-MVZK8

Horizontal Metal Panel - Vertical Joint - Plan

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.22
Discipline: Architectural

Materials

Aluminum Cold-formed Steel Metal (misc.)Steel

Elements

Expansion / Control Joints Facades / Cladding Walls Waterproofing / Flashing

Connections

Bolted Connection Rebar Splice / Development

Text on the drawing

HORIZONTAL METAL WALL PANEL SYSTEM END SPLICE FLASHING 3/4" VERTICAL HAT CHANNEL CLOSURE STRIP EXPOSED FASTENER
