The assembly features galvanized steel pipe rails supported by vertical steel posts anchored into concrete stairs. The guardrail utilizes one-inch diameter steel pipes with eight equally spaced rails reaching a height of forty-two inches. The handrail features one-and-a-quarter to two-inch diameter steel pipe mounted on one-half inch diameter steel bar supports spaced at each vertical post with a handrail height of thirty-four inches. A three-inch weep hole is located at the base of each vertical rail to drain water if grouted into the concrete.
1" DIA STL PIPE, GALV 1 1/4" DIA TO 2" DIA STL PIPE, GALV 1/2" DIA STEEL BAR HANDRAIL SUPPORTS, TYP EA VERT POST STEEL GUARD W/ HANDRAIL A STEEL HANDRAIL B CONC STAIRS BEYOND. WHERE APPLICABLE ADJUSTABLE GRADE >2'-6" TO 8 RAILS EQUALLY SPACED 42" TYP >4" MIN 6" ADJUSTABLE GRADE <2'-6" TO HANDRAIL HEIGHT TYP 34" 12" MIN 6" 3" 3" WEEP HOLE AT BASE OF EACH VERTICAL RAIL TO DRAIN WATER IF GROUTED INTO CONCRETE
