This drawing outlines accessible door clearance and hardware requirements including a plan view and an elevation view. The plan shows a ninety degree minimum open swing with a thirty-two inch minimum clear opening width between the hinge side and latch side, along with door closer requirements. The elevation indicates an eighty inch minimum exit door height, a thirty-six inch minimum exit door width, and door hardware mounted thirty to forty-four inches above the finish floor. Additional callouts specify a maximum one-half inch door threshold, door closer on the operating side of the wall, door frame, lever-operated or push-type mechanism or U-shape handle opening hardware, and interior door opening force limited to five pounds maximum with fire doors conforming to administrative authority.
