A three-quarter-inch thick steel base plate secures structural glass panels designated as 1-5/8 inch monolithic or laminated glass type GL-2. The assembly integrates an 8-inch wide by 4-inch high patch plate and a three-quarter-inch thick bearing plate with dual 4-1/2 inch diameter circular penetrations. The connection utilizes steel components specified under section 08 4400, anchored with precise dimensional spacing.
8" 1' - 2" 3/4" THK BEARING PLATE 8"Wx4"H PATCH PLATE 08 4400 1-5/8" [40 MM] MONOLITHIC, LAMINATED GLASS, GL-2 ø 4 1/2" ø 4 1/2" 2 1/2" 08 4400 STEEL, E-MTL-07 1" 1' - 0" BASE PLATE 5 1/2"
