A steel stud header frames the window head located at 2750 mm above finished floor, supported by necessary blocking and shims. A security shutter with side rails integrates into the exterior head assembly alongside a pre-finished metal flashing mounted over nineteen millimeter pressure-treated plywood finished on five sides. The interior side includes a window blind pocket with required blocking. A curtain wall assembly connects below the window head.
STEEL STUD HEADER AS PER STEEL STUD ENGINEER WINDOW BLIND. PROVIDE BLOCKING AS REQ'D WE2 92 GL WINDOW R.O. WINDOW HEAD 2750 mm AFF CURTAIN WALL (REFER TO WINDOW SCHEDULE & SPECS) SECURITY SHUTTER RAIL SHIMS AS REQ'D 19 mm P.T. PLYWOOD 92 92 152 206 450 250 25 50 75 SECURITY SHUTTER 75 244 19 35 52 PRE-FINISHED METAL FLASHING 19 mm P.T. PLYWOOD C/W PRE-FINISHED METAL FLASHING ON 5 SIDES ON 12
