Gate Keeper and Latch Assembly Detail

Materials

Concrete Steel

Elements

Columns Foundations / Footings

Connections

Welded Connection

About this detail

A gate keeper latch mechanism is mounted to a steel pipe post of a required diameter to coordinate with the hardware, with the end capped, welded, ground smooth, and painted. The post is supported by a six-inch diameter by twenty-four-inch concrete footing. A five-inch hinge connects to the gate, allowing it to swing between open and closed positions while the gate keeper holds the open gate parallel to the fence.
