Stainless steel plates are welded to form a flanged side member with dimensions of one foot four inches in overall height. A three-sixteenths-inch stainless steel plate for insulation captivation projects outward with fully threaded three-eighths-inch by one-inch stainless steel weld studs spaced at one foot one-eighth inch on center. A one-quarter-inch stainless steel plate forms the primary vertical web, secured with one-eighth-inch fillet welds spaced at two to twelve inches. The opposite side is similar but mirrored.
1'-4" 3 5/8" 2 1/2" 3" 5" 1 1/2" 1/8 2-12 1/8 OUTSIDE FACE NOTE: OPPOSITE SIDE SIMILAR BUT MIRRORED. SST PL 1/4" SST PL 3/16", FOR INSULATION CAPTIVATION 1 1/2" WELD STUD, SST, FULLY THREADED 3/8"-16 X 1" LG, 1'-0 1/8" OC
