A man ladder is installed for entry and egress into the elevator pit per manufacturer requirements. The ladder assembly spans a width of one foot six inches with a clear internal distance of one foot four inches between supports. Overall wall clearance dimensions are detailed at four and a half inches.
1" 1' - 4" 1" 4 1/2" 1' - 6" MAN LADDER FOR ENTRY AND EGRESS INTO ELEVATOR PIT, INSTALL PER MANUFACTURER REQ'S
