A steel braced frame connection with diagonal braces frames into a column through a three-eighths-inch thick gusset plate. The beam features a one-half-inch minimum bottom flange plate and a three-eighths-inch minimum top flange plate matching the bottom shape. Five-sixteenths-inch fillet welds secure the gusset plate to the structural members within a special truss moment frame system. Complete joint penetration welds with backing gas and magnetic particle testing are specified at the flange connections. Additional geometry includes a one-foot four-and-one-half-inch dimension and a six-and-one-quarter-inch clearance.
RAE 03 140' - 4 13/16" 11 R CJP, SFRS, BG, T&B MT MT REFER TO 4/3.S-327 FOR INFO NOT SHOWN BOTTOM FLANGE PL 1/2" MIN MEMBER PER PLAN 5/16 5/16 SFRS GUSSET PL 3/8" TOP FLANGE PL 3/8" MIN, SAME SHAPE AS BOTTOM 1' - 4 1/2" 1/2" 6 1/4" 7" MIN 3 3.S-331 MEMBER PER PLAN COL PER PLAN
