A-MGH35 — Roof Hatch Section

Architectural · A-MGH35

Roof Hatch Section

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: A5.03
Discipline: Architectural

Materials

Steel Metal (misc.)

Elements

Railings / Guards Roofs Decks Roof / Floor Openings

Text on the drawing

T.O. ROOF MTL. DECK 481' - 7 3/4" BETWEEN AND BELOW HANDRAILS 30" MIN CLR 3" METAL DECK R.O. 2' - 8" 2' - 6" CLR. SHIPS LADDER HATCH OPENING FRAMING ROOF HATCH ROOF ACCESS HATCH GUARDRAIL R2 A7.34 9 STEEL ANGLE
