A-MFNVH — Atrium Stair - 3rd Floor

Architectural · A-MFNVH

Atrium Stair - 3rd Floor

Scale: 1/4" = 1'-0"
Units: imperial
Sheet: A5.11
Discipline: Architectural

Elements

Floors / Slabs Roof / Floor Openings Stairs

Text on the drawing

C C D D 8 A5.11 7 A5.11 4' - 11" A5.11 13 A5.11 11 6 A5.11 5 A5.11 A5.11 12 A5.11 10 CLR. 4' - 0" A 101 9' - 3" 8' - 10" 19' - 4" OPEN TO BELOW A5.12 10 CLR 4' - 0" UP DN

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
