Evacuation map signage utilizes an Apco Fullview series mounting with frame model FSV8511(V) measuring 8 1/2 inches by 11 inches in a natural satin finish. The sign insert consists of part code FV-CL holding white A01 paper for a map provided by the architect.
EVACUATION MAP SIGNAGE APCO FULLVIEW SERIES MOUNTING: VT FRAME: FSV8511(V) SIZE: 8 1/2" x 11" COLOR: NATURAL SATIN SIGN INSERT: PART CODE: FV-CL SIZE: 8 1/2" x 11" PAPER: A01 WHITE MAP: PROVIDED BY ARCHITECT TYPE G
