An isometric assembly detail shows a Schedule 40 PVC sleeve passing through interior and exterior fume hood walls. Each end of the PVC sleeve is fitted with an NPT flange and secured with a PVC pipe end cap. The pass-through assembly is based on Scientific Plastics Inc. rigid pass-through model numbers W38547 and W38548.
INTERIOR FUME HOOD WALL EXTERIOR FUME HOOD WALL PVC PIPE END CAP - NPT (TYP). NPT FLANGE (TYP). SCHEDLE 40 PVC SLEEVE THROUGH WALL. BASED ON SCIENTIFIC PLASTICS INC. RIGID PASS THROUGH MODEL# W38547 & W38548 1/2" = 1'-0" 2 FUME HOOD - PRE-PIPING
