An aluminum door frame is anchored to cold-formed metal stud framing finished with gypsum board layers. A painted sheet metal closure finishes the return at the opening. Batt insulation fills the wall cavity, and an additional gypsum board layer is provided where required. The door slab is installed per the door schedule for openings up to 3'-0".
1 1/2" BATT INSULATION ADDITIONAL GYP BD LAYER WHERE OCCURS METAL STUD FRAMING GYP BOARD ALUM DOOR FRAME DOOR SEE DOOR SCHEDULE NOTE: FOR OPENINGS UP TO 3'-0" PAINTED SHEET METAL CLOSURE 1 1/2"
