An exterior door sill detail showing the door assembly bearing on a concrete slab on grade with an aluminum threshold and automatic door shoe as specified. The void beneath the threshold is filled solid with non-shrink grout. A continuous one-half-inch preformed expansion joint with sealant is provided in the slab adjacent to the exterior side of the threshold. Interior floor finishes vary per finish plans, and the slab on grade is constructed per structural slab plans.
DOOR AS SCHEDULED AUTOMATIC DOOR SHOE AS SPECIFIED ALUMINUM THRESHOLD AS SPECIFIED CONTINUOUS 1/2" PREFORMED EXPANSION JOINT WITH SEALANT FILL VOID UNDER THRESHOLD SOLID WITH NON-SHRINK GROUT 1/2" MAX SLAB ON GRADE. REFER TO SLAB PLANS INTERIOR FLOOR FINISH VARIES. SEE FINISH PLANS EXTERIOR INTERIOR
