Three-quarter-inch plastic laminate panels with a medium-density fiberboard core meet at a mitered outside corner return. Panels are secured using number ten sheet metal screws spaced per the manufacturer's recommendation. One-half-inch hanging cleats and shims as needed provide backing alignment. A T-trim reglet molding finishes the corner joint.
MITERED RETURN 3/4" P-LAM PANEL W/ MDF CORE T TRIM REGLET MOLDING #10 SMS SPACED PER MFR RECOMMENDATION SHIM AS NEEDED 1/2" HANGING CLEAT, SPACED PER MFR RECOMMENDATION ALIGN
