An extended shear tab connection is detailed at a structural steel column with internal stiffener plates welded to the flanges and web. The assembly incorporates a five-sixteenth-inch minimum plate measuring twelve and three-quarters by three and seven-eighths inches for the stiffeners, along with similar half-inch minimum plate elements at grid fifteen. Additional information is referenced on structural sheets S-326 and S-508 for conditions not fully shown.
6" MIN 3" RAE 01 109' - 10 3/4" X PL 5/8" MIN, 12 3/4" X 3 7/8" PL 1/2" MIN, 12 3/4" X 3 7/8", NA AT GRID 15 SHEAR TAB, REFER TO 1/3.S-326 FOR INFO NOT SHOWN REFER TO 1/3.S-508 FOR INFO NOT SHOWN EXTENDED SHEAR TAB NA AT GRID 15, USE TYP SHEAR CONNECTION STIFFENER STIFFENER
