A-MB8NS — DETAIL - ATRIUM SOUTH EAVE

Architectural · A-MB8NS

DETAIL - ATRIUM SOUTH EAVE

Scale: 3" = 1'-0"
Units: imperial
Sheet: A7.31
Discipline: Architectural

Materials

Metal (misc.)Steel Timber / Wood

Elements

Beams Facades / Cladding Roofs Waterproofing / Flashing

Text on the drawing

3/4" 1/2" EAVE FLASHING. ALIGN WITH GABLE FLASHING SHEET METAL EAVE CLADDING CLEAT WRB 2X WOOD. RIP TO MATCH REQUIRED DIIMS STEEL BEAM PER STREUCTURAL 2X WOOD NAILER METAL ROOFING

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
