This parapet detail terminates a framed wall assembly with a pre-finished metal cap matching the aluminum curtain wall system below. Single-ply roofing is applied over rigid insulation and framing at the roof level above an existing structural steel beam and roofing deck. The exterior face features an exterior insulation finish system over framed wall construction meeting the top of the curtain wall.
B T.O.P. 32'-10" INTERIOR EXTERIOR EXTERIOR INSULATION FINISH SYSTEM OVER FRAMED WALL ALUMINUM CURTAIN WALL SYSTEM AG12.4b 1 SIM. SINGLE-PLY ROOFING OVER RIGID INSULATION PRE-FINISHED METAL CAP TO MATCH CURTAIN WAL SINGLE-PLY ROOFING OVER FRAMING WALL AG12.3g 1 SIM. EXISTING ROOFING DECK
